ASL INTERCOM VAR8 User Manual

VAR8 and Variants Operation, Commissioning, Fault Finding, and Maintenance Guide -
Is
Page 130 of 166
sue: 02 complete, approved
27.1 VAR8 Menu Description
VAR8 Menu Description
Ref. Item Description/Possible Settings
1 Configuration Access to configuration functions.
2 Tests Access to test functions: TESTS MENU.
3 Faults Access to fault monitoring functions: FAULT MENU.
4 Access When logged off, enables entry of access code.
When logged on, the ACCESS MENU sub-menu is displayed.
Default value:
‘0999’
5 System
Access to Router and System configuration functions: SYSTEM
CONFIGURATION MENU.
6 Frames Access to amplifier frame configuration functions: FRAME COMMISSIONING.
7 Date/Time
Enables the user to set the date and time. Date and time are automatically set
from ACU when networked.
8 Lamps
Performs a test of LEDs and sounder – LEDS are turned off, then on in sequence
while the sounder is turned on and off. On completion of the test, normal LED
and sounder operation resumes.
9 Monitor Access to Audio, Routing, Contacts and ANS monitoring.
Audio monitoring can also be accessed by pressing the AUDIO MON key.
10 Changeover
Enables the user to scroll through configured frame/amplifier combinations
(frame/slot). When a slot has been selected, the use is given the option to
change over (swap in the standby amplifier) or change back (install the working
amplifier).
11 Status
Enables the user to scroll through the list of configured frames. When a frame
has been selected, the sub-menus are displayed.
12 Status
Displays active faults. The user can scroll through faults using up/down keys or
the rotary encoder.
Default value:
The most recent fault.
13 Logs Access to the system and amplifier frame fault logs.
14 Accept Acknowledge active faults. Turns off the sounder and steadies the fault LED.
The FAULT ACCEPT key performs the same function.
15 Clear Clear faults. Turns off the sounder and clears the fault LED.
The FAULT CLEAR key performs the same function.
16 LogOff
Log off user – causes saving of configuration data, if modified while the user was
logged on.
17 Change-Code Change access code.
Possible values:
0000 to 9999
Default value:
‘0999’
18 Clear config Clear all configuration data. All default settings are restored.
19 Frame#nn -
Enables the user to scroll through the list of configured amplifier frames. When a
frame has been selected, the sub-menus are displayed.
Where: nn=1 to 63
When the frame name is configured, it is displayed on the right field.
Default value:
Lowest numbered frame
20 Audio
Allows the selection of an input channel (Inputs) or of amplifier and slot (Outputs)
to be routed to the on-board monitor speaker.
