9.6.2 Single Button Microphone Button Configuration 9.6.2 Single Button Microphone Button Configuration
The PTT button of a Single Button Microphone may be configured to broadcast a single output, or a group of
outputs. Pressing the PTT button will then cause the microphone audio to be routed to the programmed zone
selection.
The PTT button of a Single Button Microphone may be configured to broadcast a single output, or a group of
outputs. Pressing the PTT button will then cause the microphone audio to be routed to the programmed zone
selection.
To Program the PTT Button Zones: To Program the PTT Button Zones:
1. Select the PTT button. 1. Select the PTT button.
Menu: ConfigurationÆSystemÆRouterÆInputsÆMic/LineÆI/P #<nn>ÆSingle Button Microphone Menu: ConfigurationÆSystemÆRouterÆInputsÆMic/LineÆI/P #<nn>ÆSingle Button Microphone
ÆPROTOCOLÆPTT Zones ÆPROTOCOLÆPTT Zones
2. Program the outputs that will be selected when the PTT button is pressed.
Reference to Configuration Tool
1
2
