VAR8 and Variants Operation, Commissioning, Fault Finding, and Maintenance Guide -
Is
Page 37 of 166
sue: 02 complete, approved
Table 3 VAR8 Mic/Line Input Capabilities
Inputs Available Input Types Microphone Buttons Router Applicability
ASL Fire Microphone N/A
ASL Zoned Fire Microphone
Up to 30 microphone
buttons
Configurable for zone select, DVA routing, play
DVA, all call, cancel-all-DVAs, route reset.
ASL Paging Microphone
Up to 30 microphone
buttons
Configurable for zone select, DVA routing, play
DVA, all call, cancel-all-DVAs, route reset.
ASL Single Button Microphone PTT
Configurable for routing, see Section “9.6.2 Single
Button Microphone Button Configuration”.
Miscellaneous Input N/A
Network Channel N/A
Option available only on Input 1.
Input 1 is normally used for network operation.
Refer to Section “8.2
Slave Unit Configuration”
for configuration.
1 & 2
Unused N/A
Input is excluded from routing and audio
monitoring.
Refer to “9.7 Unused Audio Inputs”.
ASL Paging Microphone
Up to 20 microphone
buttons
Configurable for zone select, play DVA, all call,
cancel-all-DVAs, route reset.
ASL Single Button Microphone PTT
Configurable for routing, see Section “9.6.2 Single
Button Microphone Button Configuration”.
Miscellaneous Input N/A
Network Channel N/A
Option available only on Inputs 3 and 4.
Inputs 3 and 4 are normally used for network
operation.
Refer to Section “8.2
Slave Unit Configuration”
for configuration.
3 to 8
Unused N/A
Input is excluded from routing and audio
monitoring.
Refer to “9.7 Unused Audio Inputs”.
Table 4 Configurable Mic/Line Input Parameters
Input Type Surv EQ Fade Chime Gain
O/P
Gains
Pri Class Name Buttons Fallback
Fire
Microphone
9 9 9 9 9 9 9 9 9
X
9
Zoned Fire
Microphone
9 9 9 9 9 9 9 9 9 9 9
Paging
Microphone
9 9 9 9 9 9 9 9 9 9 9
Single Button
Microphone
9 9 9 9 9 9 9 9 9
9
1)
9
Miscellaneous
9 9 9 9 9 9 9 9 9
X
9
1) PTT button is configurable for zone selection.
