VAR8 and Variants Operation, Commissioning, Fault Finding, and Maintenance Guide
sue: 02 complete, approved
-
Is
Page 92 of 166 Page 92 of 166
4. Select the Router outputs controlled by this ANS sensor. 4. Select the Router outputs controlled by this ANS sensor.
Menu: ConfigurationÆSystemÆRouterÆCtrlÆRemoteÆUnit address <n>ÆAnalogue Menu: ConfigurationÆSystemÆRouterÆCtrlÆRemoteÆUnit address <n>ÆAnalogue
ÆAnalogue channel=<nn>ÆAns ÆAnalogue channel=<nn>ÆAns
L
It is possible to assign multiple (up to 12) ANS sensors to a single Router output provided
that they are connected to the same Remote I/O Unit. Where this is done the highest of the
received ANS values is used.
5. Any analogue input that is not used should be configured as ‘Unused’.
Menu: ConfigurationÆSystemÆRouterÆCtrlÆRemoteÆUnit address <n>ÆAnalogue
ÆAnalogue channel=<nn>ÆUnused
Reference to Configuration Tool
