Released Rev. C 2000-1252-01 Page 127
VersaPort 2200 Technical Manual
Appendix A: ISIM
Indexer Simulator (ISIM) Menu List
a
F5 GOTO POS Target Pos. (inch) ? Moves elevator to entered position:
Target (0 to 11.9 inches)
Speed (in/sec) ? Speed (0.1 to 2.5 inch/sec)
Accel (in/sec
2
) ? Acceleration (0.1 to 2.5 inch/sec
2
)
F6 DC MOTOR Lock Port
Unlock Port
Lock Pod Door
Unlock Pod Door
Open Latch
Close Latch
Seater In Reticle VersaPort takes no action in
response to these commands.
Seater Out Reticle VersaPort takes no action in
response to these commands.
F7 MOTOR
STATUS
Gives: Controller status,
Current position,
Desired position,
Fan count.
F8 CLEAR
ERROR
Resets all errors.
F9 AUTO CYCLE
/STOPS
CYCLE
Top position during
auto cycle?
Performs up/down auto cycle to
entered values of top and bottom
position plus speed and acceleration.
F9 stops auto cycle mode, but does
not Home VersaPort
Bottom Position?
Speed (in/sec) ?
Accel (in/sec
2
) ?
F10 MAIN Returns to Main menu.
TABLE 12 Manual Mode (Continued)
F Key Main Menu F Key Sub Menu Menu Options Explanation
