VersaPort 2200 Technical Manual
Appendix B: Communications Software
ASCII Serial Text Interface
a
Structure: ECS<space>XX=Data<CR><LF>
Where: XX = Equipment constant ID
Data = new data value
TABLE 24 Equipment Constant Codes
Equipment Con-
stant ID(XX)
Description Equivalent SECS ECID
P4 ON or OFF EXT_HOST
P6 ON or OFF PIO_MODE
P13 ON or OFF MSC_INTLK
P32 Default 2990 MIN_WAFER_POS
P33 Default 11.350 STAGE_POS
P34 Default 25 SLOT_CNT
P35 Default 0.25 inch SLOT_PITCH
P37 0 – 7 SINGLE_PORT
P38 0, 1, 3, 4, or 5 (Note 4) HOST_COMMUNICATION_OPTION
P39 0, 2, 4, 5, 7, or 8 (Note 5) CASSETTE_SIZE_OPTION
P40 0 TO 65535 (default 251) DEVICE_ID
P41
2400, 4800, 9600, or
19200 baud
COMMUNICATION BAUD RATE
P61 -126 to 126 (default = 0) Elevator homing calibration offset
P63 0, 1, OR 2 DEFAULT CASSETTE PRESENT
P67 -126 to 126 (default = 0) CASSETTE BASE OFFSET
P85 0 or 1 FSD ASCII OPTION
P86 0 or 1 STAGE SEATER OUT
P87 0 to 4500 (default = 4000) Shuttle advance Position
P89 0 or 1 (default = 0) Shuttle Option
P90 -126 to 126 (default = 0) Shuttle homing calibration offset
P91 0 or 1 (default = 0) FL-compatible host interface
P92
2400, 4800, 9600, or
19200 baud (default 9600).
TAG BAUD RATE
P98 0 or 1 BRAKE_OPTION
