Asyst Technologies VersaPort 2200 - Figure 3 Versaport Label Placement (Standard Model)

Page 16 2000-1252-01 Released Rev. C
VersaPort 2200 Technical Manual
Chapter 1: Safety
Labeling
a
FIGURE 3 VersaPort Label Placement (Standard model)
Model/Serial number label
Laser interlock label
Pinch hazard labels
CE label
Ground label
Laser label (located on
bracket cover, Tool side)
