Chapter 4: Service
CAP1 – Align Laser Detector System
a
CAP1 – Align Laser Detector System
Pre-Service
NOTE . . .
1. THIS PROCEDURE MUST ONLY BE PERFORMED BY A SERVICE ENGINEER
QUALIFIED TO ALIGN LASER SYSTEMS AND AWARE OF LASER SAFETY
PRACTICES.
2. L
ASER BEAM ALIGNMENT MAY BE PERFORMED WITH THE VERSAPORT
MOUNTED TO THE PROCESS TOOL. IF THERE IS NOT ENOUGH ACCESS TO THE
V
ERSAPORT, THE VERSAPORT SHOULD BE REMOVED TO A SUITABLE SERVICE
LOCATION. OTHERWISE, SIMPLY REMOVE THE MINIENVIRONMENT SHIELD.
Remove Minienvironment
_____1. Remove the outer shields of the minienvironment by loosening the four screws
at the top of the port plate. Do not remove screws.
CAUTION
THE MINIENVIRONMENT CAN BE EASILY DAMAGED BY
MIS-HANDLING. USE CAUTION WHEN REMOVING AND
REPLACING THE MINIENVIRONMENT.
_____2. The minienvironment is attached to the port plate in a track just below the
plate’s top edge. Grab the minienvironment at both sides and gently pull away
from the port plate. Hold both pieces of the shield to avoid the inner shield
falling as the minienvironment is removed. Set the minienvironment aside.
_____3. Loosen the two captive Phillips screws securing the connector cover panel to
the VersaPort base. Set cover aside. Disconnect power, communications, and
ground cable from the VersaPort.
Tools
Allen wrench (or hex driver), 0.050 inch
Allen wrench (or hex driver), 5/64 inch
Screwdriver, Phillips, No. 1 tip
Other Material
PC compatible computer running ISIM
Null-modem communications cable
