VersaPort 2200 Technical Manual
Chapter 4: Service
Notes on Removing and Replacing VersaPort
a
Notes on Removing and Replacing VersaPort
It is not always necessary to remove the VersaPort from the Host Tool for servicing. See
specific procedure for details. When removing the VersaPort from the Host Tool, the Host
Tool owner should be involved with the removal process, as he/she will be familiar with
the configuration of the Tool.
The removal process for a Platform Mount VersaPort will vary depending on the Tool’s
configuration, but will include removing mounting hardware from the leveling rods and
moving the VersaPort away from the Host Tool to disengage the Block Guide from the
Guide Pin.
The removal process for a BOLTS Interface VersaPort will vary depending on the Tool’s
configuration, but will include removing the clamping knobs and disengaging the
mounting socket from the mounting ball of the Host Tool.
For replacing the VersaPort to the Host Tool, refer to the appropriate VersaPort
Installation Manual (PN 2000-1253-XX for Platform Mount, 2000-1276-XX for BOLTS
Interface).
