SECS Communication
a
CEID
Collected Event I.D.
1 = Pod removed event *
2 = Pod arrived event
*
3 = Enter auto mode *
4 = Enter manual mode *
5 = Power up *
18 = End home *
20 = Failed home *
21 = Exit home
*
31 = Cmpl Port Lock
32 = Cmpl Port Unlock
33 = Failed Port Lock
34 = Failed Port Unlock
49 = End Home Calibration *
50 = Failed Home Calibration *
53 = Reach Stage
*
54 = Failed Reach Stage *
55 = Reach pos
56 = Failed Reach pos
57 = Map completed
*
58 = Failed get map *
59 = End sensor calibration *
60 = Failed sensor calibration
61 = End self-test
62 = Failed self-test
63 = MSC interlock enable
64 = MSC interlock disable
65 = PIO interlock enable
66 = PIO interlock disable
142= Latch Locked
143= Abort Latch Lock
144= Latch Unlocked
145= Abort Unlock Latch
168= Shuttle Config Chng
169= End home calibration
170= Failed Home Calibration
171= Shuttle Advanced
172= Failed Shuttle Advance
173= Retracted Shuttle
174= Failed Retracted Shuttle
175= Tag Comm Timeout
* D
ENOTES EVENTS ENABLED BY DEFAULT ON
POWER UP.
S2,F35
S2,F37
S6,F13
A5
TABLE 20 Data Dictionary (Continued)
Variable Definition Where
Used
Format
To Next Page
