Page 62 2000-1252-01 Released Rev. C
VersaPort 2200 Technical Manual
Chapter 4: Service
PSP1 – Verify Laser Sensor DAC Values
a
_____c. Repeat Step 2a to choose F4, Sensor Alignment, then select Protrude
Sensor and read DAC value. Press F4 to stop calibration.
If all DAC values are less than 30, the laser system is properly aligned. If
values are not less than or equal to 30, perform CAP “CAP1 – Align Laser
Detector System” on page 64.
_____3. With all DAC values less than or equal to 30, return the VersaPort to the Home
position.
WARNING
MECHANICAL HAZARD
A PINCH HAZARD EXISTS AT THE PORT PLATE AS IT LOWERS
TO THE PORT DOOR. KEEP HANDS AWAY FROM THE PORT
PLATE PATH.
A
PINCH HAZARD MAY EXIST AT THE BOTTOM OF THE
MINIENVIRONMENT WHEN THE PORT PLATE REACHES THE
H
OME POSITION. KEEPS HANDS AWAY FROM THE
MINIENVIRONMENT PATH.
_____a. Place the Alignment Tool back on the port door.
_____b. Select F10 (MAIN) Menu
_____c. From the MAIN Menu select F1 (AUTO).
_____d. From the AUTO menu select F2 (HOME). The port plate returns to the
Home position
_____4. Close the ISIM software program;
_____a. From the Main menu select F8 (EXIT)
_____b. Use the arrow keys to select Yes and press Enter.
_____5. Remove the Alignment Tool from the port door.
_____6. Remove 24 vdc power and communications cable from the VersaPort.
_____7. Replace the Host communication cable and 24vdc power.
_____8. Replace the connector panel cover.
