Trip Page
Envision EX5000 -54- 600-00151-001 Rev 01
3) Time—Local and UTC time in HH:MM:SS using a 24-hour clock
format.
4) Flight Plan Waypoints—Flight Plan information from your GPS.
Active waypoint is shown in magenta.
n For Flight Plan waypoints, the following data displays:
u WPT—Waypoint identifier as received from the GPS.
u BRG—Bearing to current waypoint.
u DTK—Desired track to waypoint.
u NM —Cumulative great circle distance of each flight plan
leg.
u ETE—Cumulative estimated time enroute to waypoint in
H:MM format for each flight plan leg at current ground
speed.
u ETA—Estimated time of arrival to waypoint in HH:MM
formatted for local time.
u Chart Icon—Indicates that an Instrument Procedure
chart is available for the associated airport. An “I” on the
icon indicates that at least one ILS approach chart is
available for the associated airport, on the CMax Chart
page. Chart icons only display for those airports for which
you have JeppView subscription coverage. For more
information, see Section Figure 3.1, "Not for Navigation
Watermark on Chart display" on page 26.
n Intermediate waypoints are shown with the prefix Wx:. The
Trip page includes distance (NM), waypoint name, and
METAR, if available.
Intermediate waypoints are determined by your current flight
plan. The EX5000 adds intermediate waypoints along your
flight path to provide weather information between flight plan
waypoints for longer flight plan legs. This can provide you
with a fuller picture of enroute conditions.
5) METAR Symbol—A METAR report is shown for each flight plan
waypoint that uses the same METAR condition symbols as
Note: For the Garmin 430W, if the parallel track is active, the above
data, WPT, BRFDG, DTK, NM, ETE, and ETA are not displayed.
