AVL F-FEM-CON User Manual

29
Installation
F-FEM-CON — User’s Guide
 Mounting of ground braid at insert nut
 Mounting of ground braid at ground terminal
 The following materials are recommended for grounding:
Fig. 12
Insert nut d9
Contact disk 6.1
Cu-band 11 x 2
Disk 6.4
DIN rail 35 x 7.5
7.5
11
3
5
2
Screw M6 x 25
Mounting panels
Fig. 13
EX0441 Ground braid: tin-plated Cu 10 mm
2
(rolled)
EU1675 Ground terminal 10 mm
2
EU2168 Pin-type cable socket 10 mm
2
11
3
5
