A 29
82x -yy
Assignment of load profile storage (fast access)
x: 4 for load profile MP1
5 for load profile MP2
6 for load profile MP3
Table value: (for yy = 00 Counter)
Z1 Z2 Z3 Z4 Z5 Z6 Z7 Z8 Z9 Z10
Z11
Z12
Z13
Z14
Z15
Z16
Table value: (for yy = 01 Totaling units)
S1+
S2+
S3+
S4+
S5+
S6+
S7+
S8+
S1- S2- S3- S4- S5- S6- S7- S8-
Table value: (for yy = 02 Apparent demand)
SL1
SL2
SL3
SL4
SL5
SL6
SL7
SL8
Table value: (for yy = 03 cos
)
C1+
C2+
C3+
C4+
C5+
C6+
C7+
C8+
C1- C2- C3- C4- C5- C6- C7- C8-
Example: Query to table address 824-00: Counters in load profile MP1
1 0 1 1 0 0 0 0 0 1 0 0 0 0 0 0
Expl.: The counters Z1, Z3, Z4 and Z10 will be stored in load profile MP1
830 -00
Number of stored values per registration period (from version 1.03.08 and up)
Table value: Z
Z
Z
Z
Z
Z
Z
Z
Z
Z
1
Z
1
Z
1
: for load profile MP1
Z
2
Z
2
Z
2
: for load profile MP2
Z
3
Z
3
Z
3
: for load profile MP3 (not supported by DLX)
Example: 0 1 8 0 0 8 0 0 0
Expl.:
018: load profile MP1 stores 18 values,
008: load profile MP2 stores 8 values,
000: load profile MP3 stores no values.
830 -01
Number of transmitted values per registration period
Table value: Z
Z
Z
Z
Z
Z
Z
Z
Z
Z
1
Z
1
Z
1
: for load profile MP1
Z
2
Z
2
Z
2
: for load profile MP2
Z
3
Z
3
Z
3
: for load profile MP3 (not supported by DLX)
Example: 0 1 6 0 0 8 0 0 0
Expl.:
016: load profile MP1 transmits 16 values,
008: load profile MP2 transmits 8 values,
000: load profile MP3 transmits no values.
832 -00
Device identifier
Table value: Z
Z
Z
Z
Z
Z
Z
Z Z
Z
Z
Z
Example: 0 0
0
0 0 0
0
0
0 0
0
1
Expl.: The device identifier is 0000000000000001.
832 -01
Serial number
Table value: Z
Z
Z
Z
Z
Z
Z
Z Z
Z
Z
Z
Example: 0 0
0
0 0 0
0
0
0 1 2 3
Expl.: The serial number is 0000000000000123.
901 -01
Enable time changes via SCTM
Table value: Z
Z: Flag
0: time changes via SCTM are disabled
1: time changes via SCTM are enabled
Example: 0
Expl.: time changes via SCTM are disabled
