INTRODUCTION
SPECIFICATIONS
I-E96-506B1 1 - 7
General system
specifications:
Module voltage requirements
(at bus monitor test points)
Electromagnetic/radio
frequency interference
Values not available at this time. Keep cabinet doors closed. Do not use
communication equipment any closer than 2 meters from the cabinet.
Physical dimensions
Environmental:
Room ambient temperature 0° to 55°C (32° to 131°F)
Maximum module ambient tem-
perature
70°C (158°F)
Humidity 5% to 90%, up to 55°C (131°F) noncondensing
0% to 45% at 70°C (158°F) noncondensing
Cooling (fan) 180 cfm typical
Atmospheric pressure Sea level to 3 km (1.86 mi)
Air quality Noncorrosive
Certification
Meets IEEE-472-1974 surge test requirements.
CSA certification as process control equipment in an ordinary
(nonhazardous) environment.
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
Table 1-4. Specifications
(continued)
Property Characteristics
Module Voltage (VDC)
Max Ripple
(mV, p to p)
Nom Min Max
5
+15
-15
24
4.75
+14.30
-14.30
25.50
5.25
+15.75
-15.75
27.00
50
100
100
100
Component
Height Width Depth
mm in. mm in. mm in.
IEPEP01/02 132 5.2 428.6 19 114.3 4.5
IEPEP03 175.2 6.9 428.6 19 685.8 27
IEFAN01/02 44.4 1.75 428.6 19 33.0 13
IEPMU01/02 177.8 7.0 428.6 19 317.5 12.5
IEMMU01/02 177.8 7.0 428.6 19 317.5 12.5
