10. Removal and installation of the projector covers
10.6 Installation of the front cover
Necessary tools
Flat screwdriver
How to install
1. Ensur e that no lens is m ounted.
2. Exec ute the next steps to install the front cover:
a) Ho ok the bottom side of the cover to the projector.
b) G ently push the top side of the cover into position.
c) Ensure that the locking studs click into their receivers.
Image 10-13
Mount front cover
3. Secure the front cover by locking the captive screw in the m iddle at the b ottom of the front cover.
