Barco DP2K-23B Installation Manual

4. Lamp & lamp house
4. LAMP & LAMP HOUSE
WARNING: DO NOT P ERMIT UNAUTHORIZED PERSONNEL TO PERFORM OR ATTEMPT ANY PHASE OF
XENON LAM P HA NDLING OR SERVICE. ONLY TRAINED AN D QUALIFIED TECHNICAL S ERVICE PERSONNEL
ARE ALLOWED TO HANDLE THE XEN ON LAMP.
CAUTION: Xenon comp act arc lamps are highly p ressu rized. W hen ignited, the norm al operating temperature
of the bulb increases the pressure to a level at which the bulb may explode if not handled in strict accord ance
to the manufacturer’s instructions. The bulb is stable at room temperature, but may still explode if dropped or
otherwise mishandled. W hen ever the lamp house, containing a xenon lamp , has to be dism antled or when ever
the protective container or cloth has to be removed from the xenon lamp , authorized protective clothing MU ST
be worn!
WARNING: Always wear fa ce pro tection (full face shield with neck protector) when handling xeno n lamps.
WARNING: Alw ays wear protective clothing (welder’s jacket) when handling x enon lamps.
WARNING: Alwa ys wear clean leather gloves w ith w rist protectors w hen handling xen on lamps.
Overview
• Introduction
• Removal of the lamp hous e
• Removal of the xeno n bulb lamp
• Installation of the x enon bulb lamp
• Installation of the lamp house
• Resetting the lamp parameters
• Realignment of the lamp in its reflector
R59770495 DP2K-23B 30/04/2010
27

Barco DP2K-23B Specifications

General

Contrast ratio (typical)	2000:1
Projector native resolution	2K (2048x1080)
Ethernet LAN	Yes
Ethernet LAN (RJ-45) ports	3
AC input voltage	200 - 240 V
Lamp power	4000 W

Weight and Dimensions

Depth	754 mm
Width	604 mm
Height	1129 mm
Weight	133000 g
