B. Pin configurations
B.1 Pin configurations of the communication ports
RS232IN
RS232 IN
1
-
6
-
2RXE-
Receive Data (RD or RX or RXD)
7
-
3TXE-
Transmitted Data (TD or TX o r TXD)
8
-
4
-
9
-
5 GND Signal Ground (GND)
--
General Purpos e IN/OUT
General Purpose In/Out
1
3D Input Reference P
20
3D Input Reference N
2
3D Display Reference P
21
3D Disp lay Reference N
3
GPIN 3 P (re se rved)
22
GPIN 3 N (reserved)
4
GPIN 4 P (re se rved)
23
GPIN 4 N (reserved)
5
GPIN 5 P
24
GPIN 5 N
6
GPIN 6 P
25
GPIN 6 N
7
GPIN 7 P
26
GPIN 7 N
8
GPIN 8 P
27
GPIN 8 N
9
3D Output Reference P
28
3D Output Reference N
10
GPOUT 2 P (reserved)
29
GP OUT 2 N (res e rve d )
11
GPOUT 3 P (reserved)
30
GP OUT 3 N (res e rve d )
12
GPOUT 4 P
31
GPOUT 4 N
13
GPOUT 5 P
32
GPOUT 5 N
14
GPOUT 6 P
33
GPOUT 6 N
15
GPOUT 7 P
34
GPOUT 7 N
16
GPOUT 8 P
35
GPOUT 8 N
17 reserve d 36 reserved
18 reserve d 37 reserved
19 reserve d
Ethernet port
10/100 Base-T — RJ45 port 1000 Base-T — RJ45 p ort
Pin P air Color Description Description
13
white/green
TXD+ TX0+
23
green
TXD- TX0-
32
white/orange
RXD+ RX0+
4 1 blue
—
TX1+
51
white/blue
—
TX1-
62
orange
RXD- RX0-
74
white/brown
—
Rx1+
8 4 brown
—
RX1-
3D connector
Pin Name Pin Name
1 +12V 9 +12V
126 R59770495 DP2K-23B 30/04/2010
