Barco DP2K-23B Installation Manual

B. Pin configurations
Pin Name Pin Name
2
Grnd
10
3D Input Reference -
3
Grnd
11
3D Display Reference +
4
RS232 RX
12
3D Display Reference -
5
RS232 TX
13
CONN_3D MODE -
6
CONN_3D_MODE +
14
CONN_SYNC -
7
CONN_SYNC +
15
-
8
3D Input Reference +
R59770495 DP2K-23B 30/04/2010 127

Barco DP2K-23B Specifications

General

Contrast ratio (typical)	2000:1
Projector native resolution	2K (2048x1080)
Ethernet LAN	Yes
Ethernet LAN (RJ-45) ports	3
AC input voltage	200 - 240 V
Lamp power	4000 W

Weight and Dimensions

Depth	754 mm
Width	604 mm
Height	1129 mm
Weight	133000 g
