Barco DP2K-23B Installation Manual

4. Lamp & lamp house
4.4 Installation of the xenon bulb lamp
WARNING: DO NOT P ERMIT UNAUTHORIZED PERSONNEL TO PERFORM OR ATTEMPT ANY PHASE OF
XENON LAM P HA NDLING OR SERVICE. ONLY TRAINED AN D QUALIFIED TECHNICAL S ERVICE PERSONNEL
ARE ALLOWED TO HANDLE THE XEN ON LAMP.
WARNING: This procedure may only be performed by qualified technical service personnel.
CAUTION: Xenon comp act arc lamps are highly p ressu rized. W hen ignited, the norm al operating temperature
of the bulb increases the pressure to a level at which the bulb may explode if not handled in strict accord ance
to the manufacturer’s instructions. The bulb is stable at room temperature, but may still explode if dropped or
otherwise mishandled. W hen ever the lamp house, containing a xenon lamp , has to be dism antled or when ever
the protective container or cloth has to be removed from the xenon lamp , authorized protective clothing MU ST
be worn!
WARNING: Always wear fa ce pro tection (full face shield with neck protector) when handling xeno n lamps.
WARNING: Alw ays wear protective clothing (welder’s jacket) when handling x enon lamps.
WARNING: Alwa ys wear clean leather gloves w ith w rist protectors w hen handling xen on lamps.
This procedure assumes that the anode support assembly and the side cover are already removed from the
Lamp House due to the removal of the xenon lamp.
Necessary tools
• Torque wr ench with a 2 ,5 mm Allen socket.
• Torque Allen key
• 1,5 mm Allen wrench.
• 22 mm open-end wrench.
• Torque wrench with a 22 mm hexagon socket.
• Torque wrench with a 5 mm Allen socket.
How to install
1. Install the lamp cathode adapter on the cathode of the xenon lamp. Fasten the set screw of the ca thode adapter with a torque of
2,5 Nm (1,84 lbf*ft). Use for that a torque wrench with a 2,5 mm Allen socket. M ake sure that the re is full contact between the
adapter flat surface and the lamp base.
Warning: Install the cathode adapter prior to removing the protective container or protective cloth from the xenon lamp.
36
R59770495 DP2K-23B 30/04/2010

Barco DP2K-23B Specifications

General

Contrast ratio (typical)	2000:1
Projector native resolution	2K (2048x1080)
Ethernet LAN	Yes
Ethernet LAN (RJ-45) ports	3
AC input voltage	200 - 240 V
Lamp power	4000 W

Weight and Dimensions

Depth	754 mm
Width	604 mm
Height	1129 mm
Weight	133000 g
