Barco F80-Q7 User Manual

3. Input & Communication
Param eter Value
Connectors 1x) BNC 75 ohm type IEC 60169-8, Amendme nt 2 1997, A
Bandwidth
>3 GHz
Return loss
>10dB at 3GHz
Impedance 75 ohm resistive
3.4.5 HDBase T
Specifi ca tions
Param eter Value
Reference specification HDBaseT 1.0 Specific ation, June 2010
Connector Standard RJ-45, 8P8C
Signal characteristics HDBaseT
Max. c able length (1080p/48b/60Hz) 100 m (Cat5e/6), Pixel C lock <=225HHz, Video Datarate
<=5.3Gbps
70 m (Cat5e/6), P ixel Clock >225HHz , Video Datarate
>5.3Gbps
100 m (Cat6a/7), Pixel Cloc k >225HHz, Video Datarate
>5.3Gbps
Max TMDS Cloc k Frequency
270 MHz
Max video re solution supported
1920x1200 @60 Hz (WU XG A 60Hz)
HDCP Pass-Through Yes, from Source to Projector
IR E xtension
Not Su pported
RS-232 E xtension Not Supported
10/100Mbps Ethernet Pass-Through Not Su pported
Fallback to 100BaseTx, IEEE 802.3u
Not Su pported
USB O ve r Centre Tap Not Su pported
Power O ver Ethernet Not Supported
Audio
Not Su pported
LEDs - HD Base Status Operation: Green, Left
Link/Mode: Yellow, Right
3.5 Control interfaces
About
The following control interfaces are available on the projector:
• 1x RS-232 (for projector control)
• 1x LAN/Ethernet (for projector control
• 3x USB-A ports
Overview
• RS-232
• LAN/Ethernet
• US B -A port
3.5.1 RS-232
Specifi ca tions
Param eter Value
RS-232 c onnector 1 female DB9 connector (RS232-in) for projector control and
debug
20 R5906852 F80 SERIES 21/09/2017

Barco F80-Q7 Specifications

General

Placement	Desktop
Product type	Large venue projector
Product color	Black, Silver
Market positioning	Business
Heat dissipation	2900 BTU/h
Native aspect ratio	16:10
Projection distance	- m
Projection technology	DLP
Contrast ratio (dynamic)	10000:1
Contrast ratio (typical)	1200:1
Screen size compatibility	- \
Projector native resolution	WQXGA (2560x1600)
Zoom capability	Yes
Focal length range	- mm
Light source type	Laser
Service life of light source	40000 h
Analog signal format system	-
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100 Mbit/s
Power source	AC
AC input voltage	100-240 V
AC input frequency	50-60 Hz
Power consumption (max)	850 W
Power consumption (standby)	0.5 W
Power consumption (typical)	700 W
Noise level	35 dB
Certification	CE, FCC Class A, cNemkoUS, CCC, EAC, KSA, RCM, UkrSEPRO
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	10 - 40 °C
Storage relative humidity (H-H)	20 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	680 mm
Width	480 mm
Height	227 mm
Weight	25500 g
