Transmitter Audio Path Configuration
The section sets where the transmitter audio in the transceiver is sourced. Normally
this is set to internal; in this case the transceiver’s microphone provides the
transmitter audio.
When used with a remote site operation, it can be set to “remote”, in this case the
transmit audio is input into the auxiliary sockets 600 ohm balanced audio port.
Use the Scroll keys to select setting required (example shows
“Remote”):-
press the key
