Basler BE1-11g User Manual

9424200994 Rev N 621
Figure 367. Analog Inputs - Voltage Input Connections
Figure 368. Analog Inputs - Current Input Connections
External RTD Input Connections
External 2-wire RTD input connections are shown in Figure 369. Figure 370 shows external 3-wire RTD
input connections.
Figure 369. External Two-Wire RTD Input Connections
AIN I+
AIN –
AIN V
+
RTD Module
P
006
1-38
0 – 10 Vdc
Voltage
Transducer
AIN I+
AIN –
AIN V+
RTD Module
P0061-39
4 – 20 mA
Current
Transducer
RTD1+
RTD1–
RTD1C
RTD Module
Jumper
P0
061
-40
BLACK
RED
BE1-11g RTD Module
