9400200990 Rev I DGC-2020 BESTCOMSPlus Software 4-61
Inputs
Configurable Local Inputs
This screen indicates the status of local inputs, configurable input alarms, and configurable input pre-
alarms. A red LED indicates that the status is TRUE. Refer to Figure 4-61.
Figure 4-61. Metering, Inputs, Configurable Local Inputs
Configurable Remote Inputs
When an optional CEM-2020 (Contact Expansion Module) is connected, the status of the remote inputs,
configurable remote input alarms, and configurable remote input pre-alarms are shown on this screen. A
red LED indicates that the status is TRUE. Refer to
Figure 4-62.
Figure 4-62. Metering, Inputs, Configurable Remote Inputs
