4-66 DGC-2020 BESTCOMSPlus Software 9400200990 Rev I
Figure 4-68. Metering, Event Log, Sorted by Event ID
J1939 ECU
The ECU reports operating information to the DGC-2020 through the CAN interface when the ECU is
configured for Volvo Penta. Operating parameters and diagnostic information, if supported by the ECU,
are decoded and displayed on these screens.
ECU Data
This screen displays ECU Lamp Status and ECU Data. Refer to Figure 4-69.
Figure 4-69. Metering, ECU Data
