8-2 DGC-2020 LSM-2020 (Load Share Module) 9400200990 Rev I
Type Tests
Shock
15 G in 3 perpendicular planes
Vibration
Swept over the following ranges for 12 sweeps in each of three mutually perpendicular planes with each
15-minute sweep consisting of the following:
5 to 29 to 5 Hz: 1.5 G peak for 5 min.
29 to 52 to 29 Hz: 0.036” Double Amplitude for 2.5 min.
52 to 500 to 52 Hz: 5 G peak for 7.5 min.
Ignition System
Tested in closed proximity to an unshielded, unsuppressed Altronic DISN 800 ignition system.
HALT (Highly Accelerated Life Testing)
HALT is used by many manufacturers to prove that their products will provide the user with many years of
reliable service. HALT subjects the device to extremes in temperature, shock, and vibration to simulate
years of operation, but in a much shorter period span. HALT allows Basler Electric to evaluate all possible
design elements that will add to the life of this device. As an example of some of the extreme testing
conditions, the LSM-2020 was subjected to temperature tests (tested over a temperature range of -80°C
to +130°C),
vibration tests (of 5 to 50 G at +25°C), and temperature/vibration tests (tested at 10 to 20 G
over a temperature range of -60°C to +100°C). Combined temperature and vibration testing at these
extremes proves that the LSM-2020 is expected to provide long-term operation in a rugged environment.
Note that the vibration and temperature extremes listed in this paragraph are specific to HALT and do not
reflect recommended operation levels. These operational ratings are included in Section 8 of this manual.
Environment
Temperature
Operating: –40 to 70°C (–40 to 158°F)
Storage: –40 to 85°C (–40 to 185°F)
Humidity: IEC 68-2-38
UL/CSA Approvals
“cURus” recognized to UL 508 and CSA C22.2 No.14
“cURus” recognized per Standard 1604, Electrical Equipment for Use in Class I and II, Division 2, and
Class III Hazardous (Classified) Locations, Class I, Division 2, Zone 2, Groups A, B, C, D,
Temperature Code - T4.
NFPA Compliance
Complies with NFPA Standard 110, Standard for Emergency and Standby Power.
CE Compliance
This product complies with the requirements of the following EC Directives:
• Low Voltage Directive (LVD) - 73/23/EEC as amended by 93/68/EEC
• Electromagnetic Compatibility (EMC) - 89/336/EEC as amended by 92/31/EEC and 93/68/EEC
This product conforms to the following Harmonized Standards:
• EN 50178:1997 - Electronic Equipment for use in Power Installations
• EN 61000-6-4:2001 - Electromagnetic Compatibility (EMC), Generic Standards, Emission Standard
for Industrial Environments
• EN 61000-6-2:2001 - Electromagnetic Compatibility (EMC), Generic Standards, Immunity for
Industrial Environments
Physical
Weight: 0.66 kg (1.45 lb)
Dimensions: See Installation later in this section.
