9400200990 Rev I DGC-2020 Modbus™ Communication B-31
Holding
Register
Parameter Range
Read/Write
Supported
Data
Format
Units
44630
AVR Bias Output Limit Pre-alarm
Activation Delay
1-15 R W Seconds in increments of 1
44632
AVR Bias Output Limit Pre-alarm
Enable
0-1 R W
0 = Disable
1 = Enable
44634
GOV Bias Output Limit Pre-alarm
Activation Delay
1-15 R W Seconds in increments of 1
44636
GOV Bias Output Limit Pre-alarm
Enable
0-1 R W
0 = Disable
1 = Enable
44638 ID Missing Pre-alarm Enable 0-1 R W
0 = Disable
1 = Enable
44640 ID Repeat Pre-alarm Enable 0-1 R W
0 = Disable
1 = Enable
44642
CEM Comm Failure Pre-alarm
Enable
0-1 R W
0 = Disable
1 = Enable
44644-748 RESERVED
METERING
44750 Gen VAB Metering 0 - 4294967295 R Volts in increments of 1
44752 Gen VBC Metering 0 - 4294967295 R Volts in increments of 1
44754 Gen VCA Metering 0 - 4294967295 R Volts in increments of 1
44756 Gen VAN Metering 0 - 4294967295 R Volts in increments of 1
44758 Gen VBN Metering 0 - 4294967295 R Volts in increments of 1
44760 Gen VCN Metering 0 - 4294967295 R Volts in increments of 1
44762 Bus Voltage Metering 0 - 4294967295 R Volts in increments of 1
44764 Gen IA Metering 0 - 4294967295 R Amps in increments of 1
44766 Gen IB Metering 0 - 4294967295 R Amps in increments of 1
44768 Gen IC Metering 0 - 4294967295 R Amps in increments of 1
44770 Gen kVA A Metering 0 - 4294967295 R kVA in increments of 1
44772 Gen kVA B Metering 0 - 4294967295 R kVA in increments of 1
44774 Gen kVA C Metering 0 - 4294967295 R kVA in increments of 1
44776 Gen kVA Total Metering 0 - 4294967295 R kVA in increments of 1
44778 Gen kW A Metering 0 - 4294967295 R kW in increments of 1
44780 Gen kW B Metering 0 - 4294967295 R kW in increments of 1
44782 Gen kW C Metering 0 - 4294967295 R kW in increments of 1
44784 Gen kW Total Metering 0 - 4294967295 R kW in increments of 1
44786 Power Factor Metering -1.00 to +1.00 R FP
In increments of
0.01
44788 Gen PF Lagging 0-1 R
0 = Leading
1 = Lagging
44790 Gen Frequency Metering
10 to (3 * Rated
Frequency)
R FP
Hz in increments
of 0.1
44792 Bus Frequency Metering
10 to (3 * Rated
Frequency)
R FP
Hz in increments
of 0.1
44794 Active Speed Source 1-4 R
1 = Mag Pickup
2 = Gen
4 = CANBus
44796 Engine Speed Metering 0 - 65535 R RPM in increments of 1
44798 Engine Load Metering 0 - 65535 R % in increments of 1
44800 Coolant Temp. Metering 0 - 65535 R °F or °C in increments of 1
44802 Oil Pressure Metering 0 - 65535 R psi or kPa in increments of 1
44804 Battery Voltage Metering 0 - 65535 R (Volts / 10) in increments of 1
44806 Fuel Level Metering 0-100 R % in increments of 1
44808 ECU Coolant Level Metering 0-100 R % in increments of 1
44810 Cool Down Time Remaining 0-60 R Minutes in increments of 1
