9400200990 Rev I DGC-2020 BESTCOMSPlus Software 4-57
8. After file(s) have been uploaded, click the Close button on the Basler Electric Device Package
Uploader screen.
METERING EXPLORER
The Metering Explorer is a convenient tool within BESTCOMSPlus used to navigate through the following
metering screens of the DGC-2020 plug-in.
• Engine
• Generator
• Power
• Run Statistics
• Status
• Inputs
o Local Inputs
o Remote Inputs
• Outputs
o Local Outputs
o Remote Outputs
• Alarms
• Event Log
• J1939 ECU
o ECU Data
o Engine Configuration
o Active DTC
o Previously Active DTC
• MTU MDEC
o MDEC Alarms
o MDEC Fault Codes
• Summary
• Control
• Real Time Clock
• Generator Network Status
The Metering Explorer has a “Docking” feature allowing the user to arrange and dock metering screens. A
blue transparent square representing the screen being moved, seven arrow buttons, and a tabs button
appear when holding down the left mouse button on a metering tab and dragging it out. See
Figure 4-55.
Table 4
-2 explains the call-outs on Figure 4-55.
