4-10 DGC-2020 BESTCOMSPlus Software 9400200990 Rev I
A
Application Version: When configuring DGC-2020 settings off-line, the application version for the unit to
be configured must be selected. Select <1.00.07, <=1.00.07 & >1.01.00, >=1.01.00 & <1.02.00, or
>=1.02.00.
B
Application Version: Read-only value obtained when BESTCOMSPlus is communicating with the DGC-
2020.
C
Boot Code Version: Read-only value obtained when BESTCOMSPlus is communicating with the DGC-
2020.
D
Application Build: Read-only value obtained when BESTCOMSPlus is communicating with the DGC-
2020.
E
Serial Number: Read-only value obtained when BESTCOMSPlus is communicating with the DGC-
2020.
F
Application Part Number: Read-only value obtained when BESTCOMSPlus is communicating with the
DGC-2020.
G
Model Number: Read-only value obtained when BESTCOMSPlus is communicating with the DGC-
2020.
H
Language Module Version: Read-only value obtained when BESTCOMSPlus is communicating with
the DGC-2020.
I
Language Module Part Number: Read-only value obtained when BESTCOMSPlus is communicating
with the DGC-2020.
J
Device Name: Accepts an alphanumeric character string of up to 16 characters.
K
Application Version: Read-only value obtained when BESTCOMSPlus is communicating with an
optional LSM-2020.
L
Boot Code Version: Read-only value obtained when BESTCOMSPlus is communicating with an
optional LSM-2020.
M
Application Build: Read-only value obtained when BESTCOMSPlus is communicating with an optional
LSM-2020.
N
Serial Number: Read-only value obtained when BESTCOMSPlus is communicating with an optional
LSM-2020.
O
Application Part Number: Read-only value obtained when BESTCOMSPlus is communicating with an
optional LSM-2020.
P
Model Number: Read-only value obtained when BESTCOMSPlus is communicating with an optional
LSM-2020.
Q
Refresh: Clicking this button will refresh the screen after connecting an optional LSM-2020.
R
Application Version: Read-only value obtained when BESTCOMSPlus is communicating with an
optional CEM-2020.
S
Boot Code Version: Read-only value obtained when BESTCOMSPlus is communicating with an
optional CEM-2020.
T
Application Build: Read-only value obtained when BESTCOMSPlus is communicating with an optional
CEM-2020.
U
Serial Number: Read-only value obtained when BESTCOMSPlus is communicating with an optional
CEM-2020.
V
Application Part Number: Read-only value obtained when BESTCOMSPlus is communicating with an
optional CEM-2020.
W
Model Number: Read-only value obtained when BESTCOMSPlus is communicating with an optional
CEM-2020.
X
Refresh: Clicking this button will refresh the screen after connecting an optional CEM-2020.
Device Security Setup
Password protection guards against unauthorized changing of DGC-2020 settings. DGC-2020 passwords
are case sensitive. Three levels of password protection are available. Each level is described in the
following paragraphs.
• OEM Access. This password level allows access to all settings. The default, OEM-access password
is OEM.
• Settings Access. This password level allows all except uploading of firmware and clearing of device
event log. The default, settings-access password is SET.
• Operator Access. The default, operator-access password is OP. This password level allows all
settings to be read and allows changes to be made to the following:
o LCD Contrast
