Basler DGC-2020 User Manual

9400200990 Rev I DGC-2020 Modbus™ Communication B-13
Holding
Register
Parameter Range
Read/Write
Supported
Data
Format
Units
40281
Embedded Code Version Number
(a)
0-99 R
40282
Embedded Code Version Number
(b)
0-9999 R
40283
Embedded Code Version Number
(c)
0-9999 R
40287-97 RESERVED
40298
Read Relay Image of both Main
and Aux Output
individual bits
are 0 or 1
R
Main is in lower byte and Aux is in
upper byte.
b0 = Aux Output 1,
b1 = Aux Output 2,
b2 = Aux Output 3,
b3 = Aux Output 4,
b4 = Aux Output 5,
b5 = Aux Output 6,
b6 = Aux Output 7,
b7 = Aux Output 8.
b8 = Master Start Relay,
b9 = Fuel Solenoid Relay,
b10 = PreHeat PreLube Relay,
b11 = Alarm Relay,
b12 = UNASSIGNED,
b13 = Buzzer On,
b14 = EPS Loaded Relay,
b15 = PreAlarm Relay,
40299 RESERVED
J1939 DIAGNOSTIC TROUBLE CODES
40300
Active DTC Number 16 – Lower
Two Bytes
0-65535 R
Half of a set of DTC data as defined in
SAE J1939-73
40301
Active DTC Number 16 – Upper
Two Bytes
0-65535 R
Half of a set of DTC data as defined in
SAE J1939-73
40302
Active DTC Number 15 – Lower
Two Bytes
0-65535 R
Half of a set of DTC data as defined in
SAE J1939-73
40303
Active DTC Number 15 – Upper
Two Bytes
0-65535 R
Half of a set of DTC data as defined in
SAE J1939-73
40304
Active DTC Number 14 – Lower
Two Bytes
0-65535 R
Half of a set of DTC data as defined in
SAE J1939-73
40305
Active DTC Number 14 – Upper
Two Bytes
0-65535 R
Half of a set of DTC data as defined in
SAE J1939-73
40306
Active DTC Number 13 – Lower
Two Bytes
0-65535 R
Half of a set of DTC data as defined in
SAE J1939-73
40307
Active DTC Number 13 – Upper
Two Bytes
0-65535 R
Half of a set of DTC data as defined in
SAE J1939-73
40308
Active DTC Number 12 – Lower
Two Bytes
0-65535 R
Half of a set of DTC data as defined in
SAE J1939-73
40309
Active DTC Number 12 – Upper
Two Bytes
0-65535 R
Half of a set of DTC data as defined in
SAE J1939-73
40310
Active DTC Number 11 – Lower
Two Bytes
0-65535 R
Half of a set of DTC data as defined in
SAE J1939-73
40311
Active DTC Number 11 – Upper
Two Bytes
0-65535 R
Half of a set of DTC data as defined in
SAE J1939-73
40312
Active DTC Number 10 – Lower
Two Bytes
0-65535 R
Half of a set of DTC data as defined in
SAE J1939-73
40313
Active DTC Number 10 – Upper
Two Bytes
0-65535 R
Half of a set of DTC data as defined in
SAE J1939-73
40314
Active DTC Number 9 – Lower
Two Bytes
0-65535 R
Half of a set of DTC data as defined in
SAE J1939-73
40315
Active DTC Number 9 – Upper
Two Bytes
0-65535 R
Half of a set of DTC data as defined in
SAE J1939-73
40316
Active DTC Number 8 – Lower
Two Bytes
0-65535 R
Half of a set of DTC data as defined in
SAE J1939-73
40317
Active DTC Number 8 – Upper
Two Bytes
0-65535 R
Half of a set of DTC data as defined in
SAE J1939-73
40318
Active DTC Number 7 – Lower
Two Bytes
0-65535 R
Half of a set of DTC data as defined in
SAE J1939-73
