9400200990 Rev I DGC-2020 Modbus™ Communication B-27
Holding
Register
Parameter Range
Read/Write
Supported
Data
Format
Units
44324 3 Phase Overcurrent Curve (51-2) 0-16 R W
0 = S1 Curve
1 = S2 Curve
2 = L1 Curve
3 = L2 Curve
4 = D Curve
5 = M Curve
6 = I1 Curve
7 = I2 Curve
8 = V1 Curve
9 = V2 Curve
10 = E1 Curve
11 = E2 Curve
12 = A Curve
13 = B Curve
14 = C Curve
15 = G Curve
16 = F Curve
44326
3 Phase Overcurrent Alarm
Configuration (51-2)
0-2 R W
0 = None
1 = Alarm
2 = Pre-Alarm
44328 1 Phase Overcurrent Pickup (51-2)
18-118 1A
90-7750 5A
R W (Sec Amps / 100) in increments of 1
44330
1 Phase Overcurrent Time Dial (51-
2)
0-99 R W (Units / 10) in increments of 1
44332 1 Phase Overcurrent Curve (51-2) 0-16 R W
0 = S1 Curve
1 = S2 Curve
2 = L1 Curve
3 = L2 Curve
4 = D Curve
5 = M Curve
6 = I1 Curve
7 = I2 Curve
8 = V1 Curve
9 = V2 Curve
10 = E1 Curve
11 = E2 Curve
12 = A Curve
13 = B Curve
14 = C Curve
15 = G Curve
16 = F Curve
44334
1 Phase Overcurrent Alarm
Configuration (51-2)
0-2 R W
0 = None
1 = Alarm
2 = Pre-Alarm
44336
3 Phase Undervoltage Pickup (27-
2)
70-576 R W Volts in increments of 1
44338
3 Phase Undervoltage Activation
Delay (27-2)
0-300 R W (Seconds / 10) in increments of 1
44340
3 Phase Undervoltage Inhibit
Frequency (27-2)
20-400 R W Hz in increments of 1
44342
3 Phase Undervoltage Alarm
Configuration (27-2)
0-2 R W
0 = None
1 = Alarm
2 = Pre-Alarm
44344
1 Phase Undervoltage Pickup (27-
2)
70-576 R W Volts in increments of 1
44346
1 Phase Undervoltage Activation
Delay (27-2)
0-300 R W (Seconds / 10) in increments of 1
44348
1 Phase Undervoltage Inhibit
Frequency (27-2)
20-400 R W Hz in increments of 1
44350
1 Phase Undervoltage Alarm
Configuration (27-2)
0-2 R W
0 = None
1 = Alarm
2 = Pre-Alarm
44352 3 Phase Overvoltage Pickup (59-2) 70-576 R W Volts in increments of 1
44354
3 Phase Overvoltage Activation
Delay (59-2)
0-300 R W (Seconds / 10) in increments of 1
