9400200990 Rev I DGC-2020 Introduction i
INTRODUCTION
This instruction manual provides information about the operation and installation of the DGC-2020 Digital
Genset Controller. To accomplish this, the following information is provided:
• General Information and Specifications
• Controls and Indicators
• Functional Description
• Graphical User Interface Operation
• Installation
• Maintenance and Troubleshooting
• LSM-2020 (Load Share Module)
• CEM-2020 (Contact Expansion Module)
• Appendices containing Time Overcurrent Characteristic Curves and Modbus™ Communication
NOTE
Be sure that the controller is hard-wired to earth ground with no smaller than 12
AWG copper wire attached to the chassis ground terminal on the rear of the unit.
When the controller is configured in a system with other devices, it is
recommended to use a separate lead to the ground bus from each unit.
WARNING!
To avoid personal injury or equipment damage, only qualified personnel should
perform the procedures in this manual.
