Basler DGC-2020 User Manual

2-6 DGC-2020 Human-Machine Interface 9400200990 Rev I
Table 2-3. Communications Screen Branches
• CANBUS SETUP
o CANBUS ENABLE
o DTC ENABLE
o ECU CONF
o CANBUS ADDR
o ECU OPT SLCT
o ECU PULSING
o ENG SHTDN TM
o PLS CYCL TM
o ECU SET TM
o RESP TIMEOUT
• RS485 SETUP
o COMM BAUD
o COMM PARITY
o MODBUS ADDR
Table 2-4. System Params Screen Branches
• SYSTEM SETTINGS
o LSM SETUP
 ENABLE
 CANBUS ADDRESS (Visible when LSM-2020 is enabled.)
 VERSION INFO (Visible when LSM-2020 is enabled.)
 TCP/IP SETTINGS (Visible when LSM-2020 is enabled.)
• IP ADDRESS
• SUBNET MASK
• GATEWAY ADDRESS
• DHCP ENABLE
o CEM SETUP
 ENABLE
 CANBUS ADDR (Visible when CEM-2020 is enabled.)
 VERSION INFO (Visible when CEM-2020 is enabled.)
o GEN CONNECT
o RATED KW
o RATED VOLTS
o RATED FREQ
o RATED RPM
o COOLDWN TIME
o EPS
 EPS THRESHLD
 LOW LINE OVERRIDE
• SCALE FACTOR
o FUEL LVL TYP
o SYSTEM UNITS
o BATTERY VOLT
o FLYWHL TEETH
o SPEED SOURCE
o MAINT RESET
o NFPA LEVEL
o HORN
o 1 PHASE O-RIDE
o RATED PF
o POWER UP DELAY
• CRANK SETTINGS
o DISCNCT LMIT
o PRECRNK DELY
o PRESTRT CNTCT
o STYLE
o # CYCLES
