2-8 DGC-2020 Human-Machine Interface 9400200990 Rev I
 THRESHOLD
 ACTIVATN DLY
o HIGH FUEL LEVEL
 ENABLE
 THRESHOLD
 ACTIVATN DLY
o ACTIVE DTC (Visible when DTC Support is enabled.)
 ENABLE
o ECU COMMS FAIL (Visible when ECU Support is enabled.)
 ENABLE
o COOLANT LEVEL
 ENABLE
 THRESHOLD
o AVR OUTPUT LIMIT (Visible when LSM-2020 is enabled.)
 ENABLE
 ACTIVATN DLY
o GOV OUTPUT LIMIT (Visible when LSM-2020 is enabled.)
 ENABLE
 ACTIVATN DLY
o INTERGENSET COMM FAIL (Visible when LSM-2020 is enabled.)
 ENABLE
o LSM COMM FAIL (Visible when LSM-2020 is enabled.)
 ENABLE
o ID MISSING (Visible when LSM-2020 is enabled.)
 ENABLE
o ID REPEAT (Visible when LSM-2020 is enabled.)
 ENABLE
o CEM COMM FAIL (Visible when CEM-2020 is enabled.)
 ENABLE
• ALARMS
o HIGH COOLANT TEMP
 ENABLE
 THRESHOLD
 ARMING DELAY
o LOW OIL PRESSURE
 ENABLE
 THRESHOLD
 ARMING DELAY
o LOW FUEL LEVEL
 ENABLE
 THRESHOLD
 ACTIVATN DLY
o OVERSPEED
 ENABLE
 THRESHOLD
 ACTIVATN DLY
o COOLANT LEVEL
 ENABLE
 THRESHOLD
• SENDER FAIL
o
COOL TEMP SENDR FAIL
 CONFIG
TYPE
 ACTIVATN DLY
NOTE
The HIGH COOLANT TEMP and LOW OIL PRESSURE alarms have an
ARMING DLY setting that disables the alarm for the specified time after engine
startup.
