Basler DGC-2020 User Manual

9400200990 Rev I DGC-2020 Human-Machine Interface 2-11
o SLIP FREQ
o REGUL OFFSET
o CLOSING ANGLE
o VS>VD
o TIME DELAY
o FAIL DELAY
Table 2-8. Bias Control Screen Branches
• AVR BIAS CONTROL
o OUTPUT (Visible when LSM-2020 is enabled.)
 TYPE
o CONTACT (Visible when OUTPUT TYPE = CONTACT.)
 TYPE
o VOLT CTRL GAINS (Visible when OUTPUT TYPE = ANALOG.)
 KP
 KI
 KD
 TD
 LOOP GAIN
• GOV BIAS CONTROL
o OUTPUT (Visible when LSM-2020 is enabled.)
 TYPE
o CONTACT (Visible when OUTPUT TYPE = CONTACT.)
 TYPE
o SPEED TRIM
 ENABLE
o SPEED CTRL GAINS (Visible when OUTPUT TYPE = ANALOG.)
 KP
 KI
 KD
 TD
 LOOP GAIN
o KW CTRL
 LOAD CTRL ENABLE
 KP
 KI
 KD
 TD
 LOOP GAIN
 DROOP
 DROOP GAIN
 RAMP RATE
 BASELOAD LVL
 BRKR OPEN PT
Table 2-9. Multigen Management Screen Branches
• AVR ANALOG OUTPUT
o OUTPUT TYPE
o MIN OUTPUT
o MAX OUTPUT
o VOLT RESPONSE
• GOV ANALOG OUTPUT
o OUTPUT TYPE
o MIN OUTPUT
o MAX OUTPUT
o SPD RESPONSE
• LOAD SHARE LINE
o MIN VOLTAGE
o MAX VOLTAGE
