Configuring the Camera
4-14 BASLER L304kc
Draft
4.2.2.3 Feature Control and Status Register Details
Video Data Output Mode CSR
Exposure Time Control Mode CSR
Register Base Address: 0x1700
Field Name: Register Status Offset: 0x0000 Size: 1 Byte Type: Read only
Description: The integer value in this field indicates the status of this control register:
0x00 = The register is not available
0x01 = The register is available. All related settings are OK
0x80 = A value in the register is set out of range
Field Name: Mode Offset: 0x0001 Size: 1 Byte Type: Read / Write
Description: Writing an integer value to this field sets the video data output mode:
0x08 = 3 tap 8 bit output (30 MHz)
0x0A = 2 tap 8 bit output (60 MHz)
0x0C = 2 tap 10 bit output (60 MHz)
See Section 2.5.5 for a description of the video data output modes.
Register Base Address: 0x1400
Field Name: Register Status Offset: 0x0000 Size: 1 Byte Type: Read only
Description: The integer value in this field indicates the status of this control register:
0x00 = The register is not available
0x01 = The register is available. All related settings are OK
0x80 = A value in the register is set out of range
Field Name: Mode Offset: 0x0001 Size: 1 Byte Type: Read / Write
Description: Writing an integer value to this field sets the exposure time control mode:
0x00 = Free-run, programmable
0x02 = Free-run, edge-controlled
0x04 = ExSync, level-controlled
0x05 = ExSync, programmable
0x06 = ExSync, edge-controlled
See Section 2.5.5 for a description of the video data output modes.
