Introduction
1-2 BASLER L304kc
Draft
1.2 Performance Specifications
Category
Specification
Sensor Kodak KLI-4104 Linear CCD with 3 parallel color lines
(one green, one red, one blue)
Number of Pixels
4080 per line
Pixel Size 10.0 µm x 10.0 µm (10.0 µm pitch)
Center-to-center
Spacing Between Lines
90 µm
Fill Factor
100%
Spectral Response 350 nm to 1050 nm (See Figure 1-2)
Camera Link
Pixel Clock Speed
30 MHz in 3 tap output mode
60 MHz in 2 tap output modes
Maximum Data Rate
28 MPixels/s
Maximum Line Rate
7.2 kHz
Minimum Line Rate
10 Hz in free-run
No minimum when an ExSync signal is used
(For proper operation, exposure time should not be less then 10%
of the line period.)
Video Output Type
Camera Link LVDS - Base configuration
RS-644 LVDS when used with an optional Basler Interface
Converter (k-BIC)
Video Data
Output Modes
3 taps (three pixels per clock cycle)
8 bits per pixel
2 taps (two pixels per clock cycle)
Selectable 8 or 10 bit pixel depth
Synchronization
Via external ExSync signal or free-run
Exposure Time Control Edge-controlled, level-controlled or programmable
Gain and Offset Programmable via a serial link
Connectors One, 26-pin, female MDR connector
One, 6-pin, Hirose micro-miniature receptacle
Power Requirements
12 VDC ± 10%
Max 9.0 W @ 12 VDC
Lens Adapters
F-mount
Housing Size
(L x W x H)
without lens adapter: 41.3 mm x 71 mm x 71 mm
with F-mount adapter: 79.1 mm x 71 mm x 71 mm
Weight
without lens adapter: ~ 310 g
with F-mount adapter: ~ 420 g
Conformity
CE, FCC
Table 1-1: Performance Specifications
