Configuring the Camera
BASLER L304
kc 4-21
Draft
Green Gain CSR
Blue Gain CSR
Gain Lock CSR
Field Name: Raw Min Offset: 0x000F Size: 2 Bytes Type: Read only
Description: Minimum allowed integer value for the raw red gain setting. This field is updated to reflect
limitations caused by the way any related features are set.
The 2 bytes in this field are interpreted as follows:
Byte 1 = Low byte of the min value
Byte 2 = High byte of the min value
Field Name: Raw Max Offset: 0x0011 Size: 2 Bytes Type: Read only
Description: Maximum allowed integer value for the raw red gain setting. This field is updated to reflect
limitations caused by the way any related features are set.
The 2 bytes in this field are interpreted as follows:
Byte 1 = Low byte of the max value
Byte 2 = High byte of the max value
Register Base Address: 0x0EA0
The fields and the field descriptions in the green gain CSR are similar to those in the red gain CSR.
Register Base Address: 0x0EC0
The fields and the field descriptions in the blue gain CSR are similar to those in the red gain CSR.
Register Base Address: 0x0EE0
Field Name: Register Status Offset: 0x0000 Size: 1 Byte Type: Read only
Description: The integer value in this field indicates the status of this control register:
0x00 = The register is not available
0x01 = The register is available. All related settings are OK
0x80 = A value in the register is set out of range
Field Name: Mode Offset: 0x0001 Size: 1 Byte Type: Read / Write
Description: Writing an integer value to this field sets the gain lock mode:
0x00 = Gain lock disabled
0x01 = Gain lock enabled
See Section 3.6.2 for more information about the gain lock feature.
