Configuring the Camera
BASLER L304
kc 4-23
Draft
Green Offset CSR
Blue Offset CSR
Field Name: Raw Red Offset Offset: 0x000D Size: 2 Bytes Type: Read / Write
Description: Writing an integer value to this field sets the red offset.
When the camera is set for 8 bit output, the value can normally range from -400 (0xFE70)
to +400 (+0x0190).
When the camera is set for 10 bit output, the value can normally range from -1600
(0xF9C0) to +1600 (+0x0640).
When the offset lock feature (see Section 3.6.4) is enabled, the upper and lower limits of
this range may be restricted. Before writing to this field, be sure to check the values in the
Raw Min and Raw Max fields.
The DN of red offset that will be applied at a given setting in this field is determined by this
formula:
DN = setting / 2
For example, if the value in this field is set to +15 (0x000F), then:
DN = 15 / 2
DN = 7.5
The 2 bytes in this field are interpreted as follows:
Byte 1 = Low byte of the raw value
Byte 2 = High byte of the raw value
See Section 3.6.3 for more information about the red offset.
Field Name: Raw Min Offset: 0x000F Size: 2 Bytes Type: Read only
Description: Minimum allowed integer value for the raw red offset setting. This field is updated to reflect
limitations caused by the way any related features are set.
The 2 bytes in this field are interpreted as follows:
Byte 1 = Low byte of the min value
Byte 2 = High byte of the min value
Field Name: Raw Max Offset: 0x0011 Size: 2 Bytes Type: Read only
Description: Maximum allowed integer value for the raw red offset setting. This field is updated to reflect
limitations caused by the way any related features are set.
The 2 bytes in this field are interpreted as follows:
Byte 1 = Low byte of the max value
Byte 2 = High byte of the max value
Register Base Address: 0x0FA0
The fields and the field descriptions in the green offset CSR are similar to those in the red offset CSR.
Register Base Address: 0x0FC0
The fields and the field descriptions in the blue offset CSR are similar to those in the red offset CSR.
