Basler L304kc User Manual

Configuring the Camera
BASLER L304
kc 4-35
Draft
Green Color Shift Correction CSR
Blue Color Shift Correction CSR
Field Name: Raw Red Color Shift Correction Offset: 0x000D Size: 2 Bytes Type: Read / Write
Description: Writing an integer value to this field sets the line period.
The value can range from a minimum of 1 (0x0001) to a maximum of 65535 (0xFFFF).
The amount of red color shift that the camera will apply at a given setting in this field is de-
termined by this formula:
For example, if the value in this field is set to 270 (0x00F0), then:
Red color shift = 42.228731
The 2 bytes in this field are interpreted as follows:
Byte 1 = Low byte of the raw value
Byte 2 = High byte of the raw value
See Section 3.10.4 for more information about color shift correction.
Field Name: Raw Min Offset: 0x000F Size: 2 Bytes Type: Read only
Description: Minimum allowed integer value for the raw red color shift correction setting. This field is up-
dated to reflect limitations caused by the way any related features are set.
The 2 bytes in this field are interpreted as follows:
Byte 1 = Low byte of the min value
Byte 2 = High byte of the min value
Field Name: Raw Max Offset: 0x0011 Size: 2 Bytes Type: Read only
Description: Maximum allowed integer value for the raw red color shift correction setting. This field is
updated to reflect limitations caused by the way any related features are set.
The 2 bytes in this field are interpreted as follows:
Byte 1 = Low byte of the max value
Byte 2 = High byte of the max value
Register Base Address: 0x4040
The fields and the field descriptions in the green color shift correction CSR are similar to those in the red
color shift correction CSR.
Register Base Address: 0x4060
The fields and the field descriptions in the blue color shift correction CSR are similar to those in the red
color shift correction CSR.
Red Color Shift log
raw setting 4 +
5
------------------------------------------
⎝⎠
⎛⎞
24.286406×=
Red Color Shift log
270 4 +
5
-----------------------
⎝⎠
⎛⎞
24.286406×=
