Camera Interface
2-4 BASLER L304kc
Draft
2.1.3 Connector Types
26-Pin Connector
The 26-pin connector on the camera is a female 0.050 inch MDR connector as called for in the
Camera Link Specification.
6-Pin Connector
The 6-pin connector on the camera is a Hirose micro-miniature locking receptacle (part # HR10A-
7R-6PB) or the equivalent. The recommended mating connector is the Hirose micro-miniature
locking plug (part # HR10A-7P-6S). A plug of this type will be shipped with each camera. The plug
should be used to terminate the cable on the power supply for the camera.
2.2 Cable Information
2.2.1 Camera Link Cable
A Camera Link compatible MDR cable assembly is available from Basler as a stock item (part #
1000013041 for a 3 meter cable and part # 1000013042 for a 5 meter cable). As an alternate, you
can use the cable assembly manufactured by 3M (part # 14X26-SZLB-XXX-0LC).
The maximum allowed length for the MDR cable used with an L304
kc is 10 meters.
2.2.2 Power Cable
A Hirose, 6-pin locking plug will be shipped with each camera. This plug should be used to connect
the power supply cable to the camera.
For proper EMI protection, the power supply cable attached to this plug must be a twin-cored,
shielded cable. Also, the housing of the Hirose plug must be connected to the cable shield and
the cable must be connected to earth ground at the power supply.
Power requirements are given in Section 2.8.
L
Note that in order to access the Integrate Enabled signal, you must use the Basler
stock cable (see Sect. 2.5.6).
