Configuring the Camera
4-2 BASLER L304kc
Draft
4.1 Configuring the Camera with the Camera
Configuration Tool Plus (CCT+)
The Camera Configuration Tool Plus (CCT+) is a Windows
™
based program used to easily
change the camera’s parameter settings. The tool communicates via the RS-644 serial connection
in the Camera Link interface between the frame grabber and the camera. The tool automatically
generates the binary programming commands that are described in Section 4.3. For instructions
on installing the tool, see the installation booklet that was shipped with the camera.
This manual assumes that you are familiar with Microsoft Windows and that you have a basic
knowledge of how to use programs. If not, please refer to your Microsoft Windows manual.
4.1.1 Opening the Configuration Tool
1. Make sure that the properties for the RS-644 serial port on your frame grabber are properly
configured and that the camera has power.
2. To start the CCT+, click Start, click All Programs, click Basler Vision Technologies and click
CCT+ (default installation).
During start-up, a start-up screen will appear.
If start-up is successful, the CCT+ will open. To familiarize yourself with using the CCT+, press
the F1 key and look through the online help file.
If an error occurs, the CCT+ is automatically closed after start-up. Refer to the CCT+
Installation Guide for possible causes.
4.1.2 Closing the Configuration Tool
Close the CCT+ by clicking on the button in the upper right corner of the window.
