Configuring the Camera
4-36 BASLER L304kc
Draft
Test Image Mode CSR
Camera Reset CSR
Register Base Address: 0x1800
Field Name: Register Status Offset: 0x0000 Size: 1 Byte Type: Read only
Description: The integer value in this field indicates the status of this control register:
0x00 = The register is not available
0x01 = The register is available. All related settings are OK
0x80 = A value in the register is set out of range
Field Name: Mode Offset: 0x0001 Size: 1 Byte Type: Read / Write
Description: Writing an integer value to this field sets the test image mode:
0x00 = Test images disabled
0x01 = Test image 1 enabled (fixed gray gradient)
0x02 = Test image 2 enabled (moving gray gradient)
0x03 = Test image 3 enabled (vertical-horizontal gray gradient)
0x04 = Test image 4 enabled (fixed red gradient)
0x05 = Test image 5 enabled (fixed green gradient)
0x06 = Test image 6 enabled (fixed blue gradient)
0x07 = Test image 7 enabled (uniform gray)
0x08 = Test image 8 enabled (uniform black)
0x09 = Test image 9 enabled (interleaved gradient)
See Section 3.11 for more information about test images.
Register Base Address: 0x0B00
Field Name: Register Status Offset: 0x0000 Size: 1 Byte Type: Read only
Description: The integer value in this field indicates the status of this control register:
0x00 = The register is not available
0x01 = The register is available. All related settings are OK
0x80 = A value in the register is set out of range
Field Name: Reset Offset: 0x0001 Size: 1 Byte Type: Read / Write
Description: Writing an integer value of 1 (0x01) to this field will initiate a camera reset. The reset be-
havior is similar to a power up reset.
