Configuring the Camera
BASLER L304
kc 4-33
Draft
Dark Noise Cancellation Mode CSR
Defective Pixel Correction Mode CSR
Register Base Address: 0x1480
Field Name: Register Status Offset: 0x0000 Size: 1 Byte Type: Read only
Description: The integer value in this field indicates the status of this control register:
0x00 = The register is not available
0x01 = The register is available. All related settings are OK
0x80 = A value in the register is set out of range
Field Name: Mode Offset: 0x0001 Size: 1 Byte Type: Read / Write
Description: Writing an integer value to this field sets the dark noise cancellation mode:
0x00 = Dark noise cancellation disabled
0x01 = Dark noise cancellation enabled
Note: In edge-controlled mode, dark noise cancellation has no effect on the image.
See Section 3.10.2 for more information about dark noise cancellation.
Register Base Address: 0x3100
Field Name: Register Status Offset: 0x0000 Size: 1 Byte Type: Read only
Description: The integer value in this field indicates the status of this control register:
0x00 = The register is not available
0x01 = The register is available. All related settings are OK
0x80 = A value in the register is set out of range
Field Name: Mode Offset: 0x0001 Size: 1 Byte Type: Read / Write
Description: Writing an integer value to this field sets the defective pixel correction mode:
0x00 = Defective pixel correction disabled
0x01 = Defective pixel correction enabled
See Section 3.10.3 for more information about the defective pixel correction feature.
