Configuring the Camera
4-34 BASLER L304kc
Draft
Color Shift Correction Mode CSR
Red Color Shift Correction CSR
Note: The amount of red color shift correction can be set by writing a floating point value to the
Absolute Red Color Shift Correction field or by writing an integer value to the Raw Red Color Shift
Correction field. Refer to Section 4.2.2.2 for an explanation of the difference between these two
fields.
Register Base Address: 0x4000
Field Name: Register Status Offset: 0x0000 Size: 1 Byte Type: Read only
Description: The integer value in this field indicates the status of this control register:
0x00 = The register is not available
0x01 = The register is available. All related settings are OK
0x80 = A value in the register is set out of range
Field Name: Mode Offset: 0x0001 Size: 1 Byte Type: Read / Write
Description: Writing an integer value to this field sets the color shift correction mode:
0x00 = Color shift correction disabled
0x01 = Color shift correction enabled
See Section 3.10.4 for more information about color shift correction.
Register Base Address: 0x4020
Field Name: Register Status Offset: 0x0000 Size: 1 Byte Type: Read only
Description: The integer value in this field indicates the status of this control register:
0x00 = The register is not available
0x01 = The register is available. All related settings are OK
0x80 = A value in the register is set out of range
Field Name: Absolute Red Color Shift Correction Offset: 0x0001 Size: 4 Bytes Type: Read / Write
Description: Writing a floating point value to this field sets the amount of red color shift correction For
example, if the value in this field is set to 10, the amount of red color shift correction will be
10.
The amount of red color shift correction can normally range from 0.0 to 100.0 in increments
of 0.000001.
The value in this field is a standard IEEE-754 single precision (32 bit) floating point number.
See Section 3.10.4 for more information about color shift correction.
Field Name: Absolute Min Offset: 0x0005 Size: 4 Bytes Type: Read only
Description: Minimum allowed floating point value for the absolute red color shift correction setting. This
field is updated to reflect limitations caused by the way any related features are set.
The value in this field is a standard IEEE-754 single precision (32 bit) floating point number.
Field Name: Absolute Max Offset: 0x0009 Size: 4 Bytes Type: Read only
Description: Maximum allowed floating point value for the absolute red color shift correction setting. This
field is updated to reflect any limitations caused by the way any related features are set.
The value in this field is a standard IEEE-754 single precision (32 bit) floating point number.
