Configuring the Camera
BASLER L304
kc 4-19
Draft
Spatial Correction Direction CSR
Spatial Correction Amount CSR
Register Base Address: 0x3300
Field Name: Register Status Offset: 0x0000 Size: 1 Byte Type: Read only
Description: The integer value in this field indicates the status of this control register:
0x00 = The register is not available
0x01 = The register is available. All related settings are OK
0x80 = A value in the register is set out of range
Field Name: Mode Offset: 0x0001 Size: 1 Byte Type: Read / Write
Description: Writing an integer value to this field sets the spatial correction direction:
0x00 = Green (Image of the object passing the camera reaches the green line first.)
0x01 = Blue (Image of the object passing the camera reaches the blue line first.)
See Section 3.5 for more information about the spatial correction feature and Section 3.5.2
for more information about the spatial correction direction.
Register Base Address: 0x3400
Field Name: Register Status Offset: 0x0000 Size: 1 Byte Type: Read only
Description: The integer value in this field indicates the status of this control register:
0x00 = The register is not available
0x01 = The register is available. All related settings are OK
0x80 = A value in the register is set out of range
Field Name: Amount Offset: 0x0001 Size: 1 Bytes Type: Read / Write
Description: Writing a value to this field enables spatial correction and sets the spatial correction
amount. The value can normally range from 0 to 27.
If the value is set to zero, spatial correction will be disabled.
If the value is set to a number other than zero, spatial correction will be enabled and the
magnitude of the value will determine the spatial correction amount. For example, if the val-
ues is set to 9, spatial correction will be enabled and the spatial correction amount will be
9 lines.
See Section 3.5 for more information about the spatial correction feature and Section 3.5.2
for more information about the spatial correction amount.
Field Name: Min Offset: 0x0002 Size: 1 Byte Type: Read only
Description: Minimum allowed integer value for the spatial correction setting.
Field Name: Max Offset: 0x0003 Size: 1 Byte Type: Read only
Description: Maximum allowed integer value for the spatial correction setting.
Field Name: Increment
Offset: 0x0004 Size: 1 Byte Type: Read only
Description: An integer value indicating the increment for the spatial correction setting.
