Configuring the Camera
BASLER L304
kc 4-25
Draft
Area of Interest Starting Pixel CSR
Register Base Address: 0x1000
Field Name: Register Status Offset: 0x0000 Size: 1 Byte Type: Read only
Description: The integer value in this field indicates the status of this control register:
0x00 = The register is not available
0x01 = The register is available. All related settings are OK
0x80 = A value in the register is set out of range
0X81 = The setting for the AOI staring pixel conflicts with the setting for the AOI length.
Field Name: Starting Pixel Offset: 0x0001 Size: 2 Bytes Type: Read / Write
Description: Writing an integer value to this field sets the starting pixel for the area of interest (AOI) fea-
ture. The value for the starting pixel can normally range from 1 (0x0001) to 4080 (0x0FF0).
The actual available range may be limited by the way any related parameters are set.
If the value is set to 1, the starting pixel in the AOI will be pixel 1. If the value is set to 2, the
starting pixel in the AOI will be pixel 2. Etc.
The 2 bytes in this field are interpreted as follows:
Byte 1 = Low byte of the starting pixel value
Byte 2 = High byte of the starting pixel value
See Section 3.7 for more information about the AOI feature.
Field Name: Min Offset: 0x0003 Size: 2 Bytes Type: Read only
Description: Minimum allowed integer value for the starting pixel setting. This field is updated to reflect
limitations caused by the way any related features are set.
The 2 bytes in this field are interpreted as follows:
Byte 1 = Low byte of the min value
Byte 2 = High byte of the min value
Field Name: Max Offset: 0x0005 Size: 2 Bytes Type: Read only
Description: Maximum allowed integer value for the starting pixel setting. This field is updated to reflect
limitations caused by the way any related features are set.
The 2 bytes in this field are interpreted as follows:
Byte 1 = Low byte of the max value
Byte 2 = High byte of the max value
Field Name: Increment Offset: 0x0007 Size: 2 Bytes Type: Read only
Description: An integer value indicating the increment for the starting pixel setting.
The 2 bytes in this field are interpreted as follows:
Byte 1 = Low byte of the max value
Byte 2 = High byte of the max value
