Configuring the Camera
BASLER L304
kc 4-7
Draft
Product ID Inquiry
Serial Number Inquiry
Camera Version Inquiry
Register Base Address: 0x0300
Field Name: Register Status Offset: 0x0000 Size: 1 Byte Type: Read only
Description: The integer value in this field indicates the status of this inquiry register:
0x00 = The register is not available
0x01 = The register is available.
Field Name: Product ID Offset: 0x0001 Size: 20 Bytes Type: Read only
Description: String containing the camera’s product ID number. The string is zero terminated if less than
20 bytes are needed and unterminated if all 20 bytes are needed.
Register Base Address: 0x0400
Field Name: Register Status Offset: 0x0000 Size: 1 Byte Type: Read only
Description: The integer value in this field indicates the status of this inquiry register:
0x00 = The register is not available
0x01 = The register is available.
Field Name: Serial Number Offset: 0x0001 Size: 20 Bytes Type: Read only
Description: String containing the camera’s serial number. The string is zero terminated if less than 20
bytes are needed and unterminated if all 20 bytes are needed.
Register Base Address: 0x0500
Field Name: Register Status Offset: 0x0000 Size: 1 Byte Type: Read only
Description: The integer value in this field indicates the status of this inquiry register:
0x00 = The register is not available
0x01 = The register is available.
Field Name: Camera Version Offset: 0x0001 Size: 3 Bytes Type: Read only
Description: The value in this field indicates the camera’s version information. The bytes in the field are
interpreted as follows:
Byte 1 = Low byte of the camera version (BCD coded)
Byte 2 = High byte of the camera version (BCD coded)
Byte 3 = Register layout ID (BCD coded)
