Operation and Features
BASLER L304
kc 3-67
Draft
Activating the Factory Set File
You can activate the factory set file with the Camera Configuration Tool Plus (CCT+) or by using
binary read/write commands from within your own application to set the camera’s bulk data control
and status registers (CSRs).
With the CCT+
With the CCT+ (see Section 4.1), you use the File Name Select parameter and the Activate User
Set parameter in the User Set Files parameters group to activate the factory set file.
By Setting CSRs
You activate the factory set file by writing values to the bulk data CSR for configuration sets. The
bulk data “activate” process is used to activate the factory set file.
Section 4.2.3 explains bulk data CSRs and using the bulk data activate process. Section 4.3.1
explains using read/write commands.
3.17.4 Which Configuration Set File will Load at Startup
or at Reset?
On the initial wake-up after delivery, the camera copies the factory configuration set into the work
set.
At each subsequent power on or reset, the configuration set file that was last activated is copied
into the work set.
If there is no activated file, the factory set file will be copied into the work set.
3.17.5 Downloading a Saved User Set File to Your PC or
Uploading a Saved User Set File From Your PC
Once you have saved a user set to a file in the camera’s non-volatile memory, you can download
the saved file to your PC. Any user set file that you have downloaded to your PC can later be
uploaded to a camera. These functions are useful if you want to transfer a user set from one
camera to another camera of the same type.
Downloading and Uploading Saved User Set Files
You can download or upload saved user set files with the Camera Configuration Tool Plus (CCT+)
or by using binary read/write commands from within your own application to set the camera’s
control and status registers (CSRs).
With the CCT+
With the CCT+ (see Section 4.1), you use the File Name Select parameter and the Download User
Set File parameter or the Upload User Set File parameter in the User Set Files parameters group
to download or upload files.
L
Before you can download a user set to you PC, you must have saved the user set
to a file in the camera’s non-volatile memory as described in Section 3.17.1.
