Introduction
BASLER L304
kc 1-1
Draft
1 Introduction
1.1 Document Applicability
This User’s Manual applies to L304kc cameras with a camera version ID number of 01.
Cameras with a lower or a higher ID number may have fewer features or have more features than
described in this manual. Features on cameras with a lower or a higher ID number may not
operate exactly as described in this manual.
An easy way to see the camera version ID number for an L304
kc camera is by using the CCT+.
To see the camera version ID number:
1. Double click the CCT+ icon on your desktop or click Start
⇒ All Programs ⇒ Basler Vision
Technologies
⇒ CCT+ ⇒ CCT+. The CCT+ window will open and the software will connect
to your camera.
2. Scroll down until you find the
“Camera Information” group
heading. If there is a plus sign
beside the Camera Information
group heading, click on the
plus sign to show the list of
parameters in the group.
3. Find the parameter called
“Camera Version.” As shown
in Figure 1-1, the last two
numbers of this parameter are
the camera version ID number.
L
You can also access the camera version ID number by using binary commands to
read the Camera Version Inquiry register. (See Section 4.2.1 for an explanation of
inquiry registers and Section 4.3 for information on using binary commands.)
This is the
camera
version
ID Number
Figure 1-1: CCT+ Window
